TLG DUO
Built for Campus Life.
Engineered for Safety.
Designed for Sharing.
DUO is a 20×3.0 utility ebike engineered around a single belief: one bike should do everything — and do it brilliantly. Built on TLG SmartDrive™ architecture, the DUO pairs a 750W hub-drive motor with 100Nm peak torque to the largest torque figure in its class, wrapped in an agile 20×3.0 tire platform that keeps the ride light, playful, and planted. Whether you're commuting to campus, hauling 420 lbs of cargo, giving a friend a ride, or launching off the line in TLG NitroBurst™ mode, DUO delivers the power you need and the fun you didn't expect. One bike. Shared across your whole family through TLG Share Digital Key. Personalized ride feel through TLG Ride Tune. 720Wh battery standard, expandable to 1440Wh for up to 140+ miles with optional extender battery. This is what a modern utility ebike should be. Powered by TLG SmartDrive™ Core · TLG NitroBurst™ · TLG Ride Tune · TLG SafeSphere™
At a Glance
Features
Features
Features
Technical Specifications
General Info
Model Name
DUO
Colors
Matte Mirage / Flat White / Eruption Green
Frame Type
Step-Thru (2-Passenger)
Size Guide
Bike Size
One Size
User Height Range
5'1" – 5'5"
Electronics
Motor
48V TLG® 750W Hub-Drive Motor · 100Nm · Efficiency ≥80%
Battery
UL2271 Certified / Internal / Removable / Lithium Ion, 48V/15Ah (720Wh) with Samsung®/LG® Cells, w/ Option for Additional 15Ah(720Wh)Rear Rack Extender Battery, IP67
Optional Battery
15Ah (720Wh) Rear-Rack Extender
Charger
2A / 100-240V Input / 54.6V Output · BC Certified · UL 62368-1 Listed
Controller
48V 750W · 12 MOS · 17A Current Limiting · CAN · Internally Potted · UL Certified · Aluminum Housing
Display
IPS Matrix 3.5" Full-Color · High Brightness · Bluetooth · Type-C Charging · Turn Signals · 7-Button Remote · Password Protection · CAN · Adjustable Angle
Torque
Torque/Cadence Switchable · CAN
Throttle
Thumb Throttle · Anti-Runaway · Removable (Class-Compliant) · Right-Side Mounted · 100,000 Cycle · IPX7 · RoHS
Pedal Assist
Smart Auto Assist · 5-Level + Nitro Burst Modes · App Ride-Tune
Rear Light
TLG® Logo Light · Turn Signal · Steady Warning · Brake Highlight · Hazard Flashers · IPX6
Front Light
90 Lux/520Lm · 48V 4.5W LED · Adjustable · K-Mark ECE · ISO 6742-2 · IPX6
IOT & App
Anti-Theft: GPS with SIM Card + Geo-Fencing + Lost-Bike Tracking · Keyless Unlock (Password / Bluetooth / Remote Authorization) · Smart Auto Assist · Ride Tune Customization · Custom Ringtones & Sounds · Custom Battery Charge Limit · Cycling Navigation · Ride Record · TLG Community · Good-to-Go Startup Self-Test · Quick Troubleshooting · Dealer Service Guide · Maintenance Recommendations · OTA Updates
Frameset
Frame
6061-T6 Hydroformed Alloy · 2-Passenger · Step-Thru · Smooth Welding
Fork
Zoom®Aluminum Suspension Fork, 80mm Travel, Tapered 1.5”,with Lock-out
Drivetrain
Crankset
Alloy Integrated forming, 52T, w/ Single Chainguard, Square Taper, 160mm
Chain
Anti-Rust KMC® 8S
Rear Derailleur
Shimano® RD-M310-L Altus · 8-Speed (Short Cage)
Cassette
Shimano® 8-Speed 12-32T
Shifter
Shimano® 8-Speed
Bottom Bracket
Square Taper Sealed Bearings · Torque & Cadence Sensors Included
Speed & Range
Max Speed Default
28 MPH
Adjustable Range
12–28 MPH
Class
1 / 2 / 3
Range
70 Miles
Brake
Brake
Tektro® Hydraulic, w/ Brake Sensors
Rotors
Front 203mm / Rear 180mm
Weight & Load
Bike Weight
72.5 Lbs
Max Bike Load
420 Lbs
Rear Rack Load Capacity
Integrated Rear Rack
Cockpit
Handlebar
Zoom® Alloy, 31.8mmx700mm Wide, 38mm Rise, 38 Deg Backswee.
Grips
Ergonomic Comfort, attachable rearview mirror, lockable
Stem
Alloy, BMX style, Top-Load, 30 Deg. Angle, 50mm Extension.
Headset
Threadless, Internal 52/56mm
Saddle
Comfort · L 268mm × W 219mm
Seat Post
Alloy · 30.9×400mm · Adjustable
Clamp
Alloy, 35mm w/ Quick Release
Wheel
Tire
KENDA® K-1016 20×3.0 · Puncture-Resistant
Rims
Alloy Double-Wall 20"×33mm · Eyelets
Spokes
Stainless 12G
Front Hub
Alloy 12G×36H · OLD 110mm · 15mm Thru
Rear Hub
48V 750W+ / 28 MPH / 100Nm
Supports
Rear Rack
Integrated Rear Rack
Fenders
Alloy 20"
Pedals
9/16" with Reflectors · Anti-Slip Studs
Kickstand
Adjustable Side Kickstand
GEOMETRY
FAQ
Got Questions? We've Got Answers: Comprehensive Insights and Detailed Explanations for All Your Frequently Asked Questions
How do I book a test ride?
How do I track my order?
How can I get an Invoice?
How do I resolve after-sales issues for my product?
How do users place an order to buy a product?
TLG DUO
100Nm • 420lbs Payload• 70Miles Range (140 w/ Extender)
